YONGJING Solenoid Valve N331/7LB Specifications
| Model Number | N331/7LB |
| Brand | Yongjing |
| Voltage | 24V DC -15% ~ +10% |
| Power | 2.3W |
| Operating Pressure | 0~7 bar |
| Fluid/ambient temperature | -5 ~+ 50¡æ |
| Maximum flow rate at 6bar with p 1bar | 30 NI/min |
| Exhaust | 50 NI/min |
| Max number of cycles per minute | 2400/min |
| Life expectancy | More than 50 Million times |
| Response time when energized | 6 ms |
| Response time when de-energized | 8ms |
| Copper wire isolation chass | F (155oC) |
